APC P1-GR Prenaponska zaštita
APC P1-GR Prenaponska zaštita

APC P1-GR Prenaponska zaštita

  • 13
    NA LAGERU
  • GARANCIJA
    24

Bar code: 731304223849

APC Esencijalna zaštita od grmljavine, prenapona i pada napona.

  • Brand
    APC
  • Tip proizvoda
    Pasiva - Prenaponska zaštita
  • Broj utičnica
    1
  • Tip utičnice
    Schuko CEE 7/7P
  • Ulazni napon [V]
    230
  • Ulazna frekvencija [Hz]
    50/60
  • Maksimalna struja po fazi [A]
    16
  • Duljina kabela [m]
    0
  • Surge rating [J]
    960
  • eP Joule Rating
    1060
  • EMI/RFI Noise rejection [dB]
    20
  • Maksimalna struja - Normal [kAmps]
    13
  • Maksimalna struja - Common [kAmps]
    13
  • Propusnost napona [V]
    <900

30,00 KMi

Detalji o proizvodu

Output

  • Number of Outlets
    1.0
  • Receptacle Style
    CEE 7 Schuko

Input

  • Nominal Input Voltage
    230V
  • Input frequency
    50/60 Hz
  • Input Connections
    Schuko CEE 7/7P
  • Maximum Line Current
    16A

Surge Protection and Filtering

  • Surge energy rating
    960Joules
  • eP Joule Rating
    1060
  • Peak Current Common Mode
    13kAmps
  • Peak Current Normal Mode
    13kAmps

Physical

  • Maximum Height
    94mm , 9.4CM
  • Maximum Width
    70mm , 7.0CM
  • Maximum Depth
    76mm , 7.6CM
  • Net Weight
    0.1KG
  • Shipping weight
    0.1KG
  • Shipping Height
    114mm , 11.4CM
  • Shipping Width
    89mm , 8.9CM
  • Shipping Depth
    95mm , 9.5CM
  • Color
    Charcoal
  • Master Carton Units
    12.0
  • Units per Pallet
    648.0
  • SCC Codes
    10731304 0

Environmental

  • Operating Temperature
    0 - 40 °C
  • Operating Relative Humidity
    0 - 95 %
  • Operating Elevation
    0-15000meters
  • Storage Temperature
    -15 - 45 °C
  • Storage Relative Humidity
    0 - 95 %
  • Storage Elevation
    0-15000meters

Conformance

  • Approvals
    CE
  • Equipment protection policy
    Lifetime : 50000 Euros
  • Standard warranty
    Lifetime, 3 years (all other countries)

Sustainable Offer Status

  • RoHS
    Compliant
  • PEP
    Available in Documentation tab
  • EOLI
    Available in Documentation tab
